SAILOR 7222 VHF DSC Class A

Included in system

• SAILOR 7224 VHF Control Unit including Power Cable
• SAILOR 6201 Handset including Cradle
• SAILOR 7226 VHF Transceiver Unit
• Note 1: Mounting accessories MUST be ordered separately
• Note 2: Connection between CU and TU must be made using a shielded LAN
• cable - up to 50m. Not included.

SUB-COMPONENTS

Name	Min. qty	Qty required
SAILOR N163S Power Supply	2	1
VHF Antenna - CX4	1	2
Mast bracket 1.25" - 11TPI incl. mounting	1	2
5m Conn. Cable 1x10 Pole	1	1
Opt. 5m Cable. RJ45 Cat5e STP	1	1

SAILOR 6210 VHF

Included in system

• Transceiver Unit (SAILOR 6210 VHF)
• SAILOR 6202 Hand Microphone with spiral cable
• User and installation manual
• Installation guide
• Mounting bracket with two-wheel knobs
• Connectors for cables
• Power cable, fittings, and fuses
• Sun Screen (click on) for front plate protection
• Kit for flush mount installation, including gasket

SUB-COMPONENTS

Name	Min. qty	Qty required
SAILOR N163S Power Supply	2	1
SAILOR 6090 Power Converter, 24V DC to 12V DC	1	1
VHF Antenna - CX4	1	1
Mast bracket 1.25" - 11TPI incl. mounting	1	1
Coax plug PL259 for RG 214/u	2	2
Coax cable RG 214/u 2 x screen	1	1

SAILOR 6103 Multi Alarm Panel

Included in system

• SAILOR 6103 GMDSS Alarm Panel For connection to VHF
• MF/HF and Mini-C Including: - DC Power Cable
• 4 pin
• U-bracket
• Flush mounting kit
• User manual.

SAILOR 6248 VHF

Included in system

• Transceiver Unit VHF
• SAILOR 6201 Handset with cradle
• U-bracket
• Flush mounting kit
• Power Cable
• SAILOR 6090 Power Converter, 24V DC to 12V DC
• User manual

SUB-COMPONENTS

Name	Min. qty	Qty required
SAILOR N163S Power Supply	2	1
VHF Antenna - CX4	1	1
Mast bracket 1.25" - 11TPI incl. mounting	1	1
Coax plug PL259 for RG 214/u	2	2
Coax cable RG 214/u 2 x screen,	1	1

SAILOR 6249 VHF Survival Craft

Included in system

• Transceiver Unit VHF
• SAILOR 6202 Hand Microphone
• U-bracket
• Flush mounting kit
• Power Cable
• SAILOR 6090A Power Converter, 24V to 12V DC
• User manual

Name	Min. qty	Qty required
SAILOR N163S Power Supply	2	1
VHF Antenna - CX4	1	1
Mast bracket 1.25" - 11TPI incl. mounting	1	1
Coax plug PL259 for RG 214/u	2	2
Coax cable RG 214/u 2 x screen,	1	1
